SECONDARY IMPACT CRUSHERS

SECONDARY IMPACT CRUSHERS

Secondary impact crushers provide high capacity and high reduction ratio for secondary crushing stage. In addition to preparing the material for the final crushers with the secondary crushing process, they also produce final product in significant capacity.

Since the materials coming out of the secondary impact crushers are cubic in shape, they are also suitable for use as products.

  • Compact and rigid body design
  • Rotor with high inertia
  • Hydraulic setting adjustment
  • Easy hammer replacement
  • Casting hammers with wear and breaking resistance
  • High reduction ratio
  • Heavy duty steel casted bearing housings
  • Heavy duty bearings
  • 3 Impact curtain

TECHNICAL SPECIFICATIONS

MODEL ROTOR DIMENSIONS (mm) MAXIMUM FEED SIZE (mm) MOTOR POWER (kW)
SDK-110 1100×1100 250 200
SDK-130 1200×1300 250 250
SDK-140 1430×1400 300 315
SDK-160 1430×1600 300 355
SDK-180 1500×1800 350 500
SDK-200 1600×2000 350 630

DIMENSIONS

MODEL A B C D E F G H I J K L M
SDK-110 1620 1520 2780 2340 2250 3540 2910 1470 1160 1180 1210 1010 500
SDK-130 1770 1800 3030 2550 2660 3870 3170 1600 1370 1390 1430 1100 550
SDK-140 2065 1940 3540 2980 2860 4510 3700 1870 1480 1500 1540 1280 640
SDK-160 2065 2220 3540 2980 3270 4510 3700 1870 1690 1710 1760 1280 640
SDK-180 2210 2490 3790 3190 3680 4830 3960 2000 1900 1930 1980 1370 690
SDK-200 2360 2770 4050 3410 4090 5150 4230 2140 2110 2140 2200 1460 730

TECHNICAL SPECIFICATIONS

MODEL ROTOR DIMENSIONS (mm) MAXIMUM FEED SIZE (mm) CAPACITY (TON/HOUR) MOTOR POWER (kW) WEIGHT (kg)
DMK-100 1200×1000 150 100-175 132-185 14.000
DMK-125 1200×1250 250 150-250 185-250 16.500
DMK-150 1200×1500 250 250-400 200-315 19.000

DIMENSIONS

MODEL A B C D E F G H I J K
DMK-100 2380 2435 3650 3595 2180 1480 1070 1120 1030 865 1370
DMK-125 2380 3600 3715 3460 2430 1725 1270 1375 1345 705 1370
DMK-150 2380 3600 3715 3460 2690 1980 1540 1630 1600 695 1370

360° View

SDK TYPE IMPACT CRUSHER

your 360 images

DMK TYPE IMPACT CRUSHER

your 360 images

PRODUCT GALLERY
